SKF 7205 BECBY ANGULAR CONTACT BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: 7205 BECBY
IMS Product Code: 1838729
Packaging: Sold Individually
Description:
SKF 7205 BECBY Angular Contact Bearing
Single-row angular contact ball bearing with 25 mm bore diameter, 52 mm outside diameter, and 15 mm width. Features a 40-degree contact angle, open closure type, and brass cage material.
Specifications
- Bore Type: Straight
- Bore Diameter: 25 mm
- Outside Diameter: 52 mm
- Overall Width: 15 mm
- Row Type: Single-Row Non-Fill Slot
- Closure Type: Open
- Duplex Type: Single
- Bearing Type: Angular Contact Bearings
- Contact Angle: 40 degrees
- Bearing Material: Steel
- Cage Material: Brass
- Internal Clearance: C0
- Radial Dynamic Load Capacity: 15.6 kN
- Radial Static Load Capacity: 10.2 kN
- Max Rpm: 15000 rpm
- Precision Rating: ABEC 3 (ISO Class 6)
- Fillet Radius: 1 mm
- Series: 72
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 9 In Stock
Ships today if ordered in the next 13 hours and 20 minutes.
