SKF 7307 BECBY ANGULAR CONTACT BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: 7307 BECBY
IMS Product Code: 1838612
Packaging: Sold Individually
Description:
SKF 7307 BECBY Angular Contact Bearing
Angular Contact Bearing - 35 mm Bore, 80 mm OD, 21 mm Width, Open, 40 degrees Contact Angle
Specifications
- Bore Type: Straight
- Bore Diameter: 35 mm
- Outside Diameter: 80 mm
- Overall Width: 21 mm
- Row Type: Single-Row Non-Fill Slot
- Closure Type: Open
- Duplex Type: Single
- Bearing Type: Angular Contact Bearings
- Contact Angle: 40 degrees
- Bearing Material: Steel
- Internal Clearance: C0
- Radial Dynamic Load Capacity: 39 kN
- Radial Static Load Capacity: 24.5 kN
- Cage Material: Brass
- Max Rpm: 10000 rpm
- Precision Rating: ABEC 3 (ISO Class 6)
- Fillet Radius: 1.5 mm
- Series: 73
- Weight: 0.468 kg
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 20 minutes.
