SKF NNF 5013 ADB-2LSV CYLINDRICAL ROLLER BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: NNF 5013 ADB-2LSV
IMS Product Code: 1862833
Packaging: Sold Individually
Description:
SKF NNF 5013 ADB-2LSV Cylindrical Roller Bearing
Double row full complement cylindrical roller bearing with cylindrical bore, 65 mm inner diameter, 100 mm outer diameter, 46 mm width, and contact seals on both sides.
Specifications
- Bore Type: Cylindrical
- Number Of Rows: 2
- Bore Diameter: 65 mm
- Outside Diameter: 100 mm
- Overall Width: 46 mm
- Ring Separation: Non-Separable
- Internal Clearance: C0
- Flanges: Two-Piece Inner Ring
- Seal Type: Contact Seal
- Max Rpm: 1300 rpm
- Bearing Material: Steel
- Cage Material: No Cage
- Closure Type: Sealed
- Fillet Radius: 0.6 mm
- Weight: 2.94 lbs
- Material Element: Bearing steel
- Locating: Snap Ring Groove
- Basic static load rating: 224
- Tolerance class: Normal
- Radial internal clearance: CN
- Relubrication feature: With
- Lubricant: Grease
- Sealing type: Contact
- Cage: Without
- Locating feature, bearing outer ring: Snap ring groove
- Bearing part: Complete bearing
- Sealing: Seal on both sides
- Number of flanges, inner ring: 2
- Number of flanges, outer ring: 1
- Limiting speed: 1300
- Axial displacement capability: None
- Basic dynamic load rating: 138
- Coating: Without
