SMC AW40-N04E-Z-B MODULAR FILTER REGULATOR
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: AW40-N04E-Z-B
IMS Product Code: 2147407
Packaging: Sold Individually
Description:
SMC AW40-N04E-Z-B Modular Filter Regulator
Modular filter regulator with 1/2" NPT port, 0.05 to 0.85 MPa pressure range, and polycarbonate bowl. Part of SMC's modular air preparation units series.
Specifications
- Adjustment Range: 7 to 123 psi
- Bowl Material: Polycarbonate
- Body Size: 40
- Certifications: RoHS
- Filter Rating: 5 micrometer
- Fluid Compatibility: air
- Inlet Port: 1/2 inch
- Manual Drain: true
- Material: Polycarbonate
- Max PSI: 145
- Max Temperature: 140 degrees F
- Maximum Pressure: 145 PSI
- Min Temperature: 23 degrees F
- Port Size: 1/2" NPT
- Pressure Range: 0.05 to 0.85 MPa
- Series: AW40-B
- Temperature Range: 23 degrees F to 140 degrees F
- Type: Modular type filter regulator
- Weight: 1.85 lbs
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships on Monday, December 1, 2025
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
