SMC D-J59WL INLINE SOLID STATE AUTO SWITCH
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: D-J59WL
IMS Product Code: 1929550
Packaging: Sold Individually
Description:
SMC D-J59WL Inline Solid State Auto Switch
Inline solid state auto switch with 2-wire tie rod design, LED indicator, 3m lead wire, band mounting, and IP67 enclosure. Detects magnetic field changes in air cylinders.
Specifications
- Series: D-
- Type: Inline Solid State Auto Switch
- Switching Voltage: 24 V DC
- Number of Wires: 2
- Lead Length: 3 m
- Switching Current: 5 to 40 mA
- Display: LED Indicator Light
- Minimum Cycle Time: 1 ms
- Operating Temperature: -10 to +60 degrees C
- Enclosure Type: IP67
- Mounting Type: Band
- Overall Width: 22 mm
- Overall Height: 14.4 mm
- Overall Length: 40.8 mm
- Weight: 0.071 kg
- Applicable Load: PLC, Relay
- Standards Met: CE, IEC 529, JIS C 0920
