SMC SV2100-5W1U-02N 5-PORT SOLENOID VALVE
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: SV2100-5W1U-02N
IMS Product Code: 1857222
Packaging: Sold Individually
Description:
SMC SV2100-5W1U-02N 5-Port Solenoid Valve
5-port solenoid valve with internal pilot, 24V DC, M12 connector, non-locking push manual override, 1/4 NPT port size.
Specifications
- Type: SV2000 SOLENOID VALVE, 5-PORT
- Weight: 0.44092 lb
- Piping Type: Manifold
- Number Of Ports: 5
- Number Of Positions: 2
- Number Of Solenoids: 1
- Solenoid Supply Voltage: 24 V dc
- Solenoid Electrical Entry: M12 Connector
- Flow Coefficient Cv Flow Factor Kv: 0.64 (P to A/B) Cv, 0.66 (A/B to EA/EB) Cv
- Manual Operation Type: Non-Locking Push
- Operating Temperature Range: 14 to 122 degrees F
- Maximum Operating Pressure: 101 psi
- Operating Medium: Air
- Flow Direction: 4-Way
- Port Sizes: 1/4 NPT
- Standards Met: JIS B 8375-1981
- Actuation: Piloted Solenoid
- Body Material: Aluminum
- Overall Height: 60.3 mm
- Overall Length: 121.4 mm
- Overall Width: 46 mm
- Response Time: 25 ms
- Solenoid Allowable Voltage Fluct: -10 to +10 %
- Solenoid Power Consumption: 0.65 W
- Sonic Conductance (C): 2.4 (P to A/B) dm³/(s.bar), 2.8 (A/B to EA/EB) dm³/(s.bar)
- Valve Function: Spool
- Pilot: Internal Pilot
- Valve Series: SV2000
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships on Monday, January 12, 2026
