SMC SY3340-5LOZ 5-PORT SOLENOID VALVE
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: SY3340-5LOZ
IMS Product Code: 1940631
Packaging: Sold Individually
Description:
SMC SY3340-5LOZ 5-Port Solenoid Valve
Double solenoid valve, base mounted, 24V DC, rubber seal, SY3000 series.
Specifications
- Series: SY3000
- Type: VALVE
- Mounting: BASE MT
- Seal Type: RUBBER SEAL
- Weight: 0.15910 lb
- Piping Type: Base Mounted
- Number Of Ports: 5
- Number Of Positions: 3 (Closed Center)
- Number Of Solenoids: Double
- Solenoid Supply Voltage: 24 V dc
- Solenoid Electrical Entry: L Plug
- Flow Coefficient Cv Flow Factor Kv: 0.29 Cv
- Manual Operation Type: Non-Locking Push
- Operating Temperature Range: 14 to 122 F
- Maximum Operating Pressure: 101 psi
- Seal Material: Rubber
- Operating Medium: Air
- Flow Direction: 4-Way
- Port Size: Without Subplate
- Standards Met: IEC 60529, JIS B 8375-1981
- Actuation: Piloted Solenoid
- Body Material: Zinc
- Overall Height: 53.5 mm
- Overall Length: 117.1 mm
- Overall Width: 22 mm
- Response Time: 15 ms
- Solenoid Allowable Voltage Fluct: ±10 %
- Solenoid Power Consumption: 0.35 W
- Sonic Conductance (C): 1.1 dm³/(s.bar)
- Valve Function: Spool
- Voltage: 24 V dc
- Thread Standard: Rc
- Bracket Type: w/o Bracket
- Coil Specifications: Standard
- Valve Series: SY3000
- Voltage Suppressor: With Light/Surge Voltage Suppressor
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships on Monday, May 18, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
