SMC VNH111A-10A-5TZ HIGH PRESSURE COOLANT VALVE
Quick Overview
Manufactured By: SMC
Manufacturer Part Number: VNH111A-10A-5TZ
IMS Product Code: 2127168
Packaging: Sold Individually
Description:
SMC VNH111A-10A-5TZ High Pressure Coolant Valve
2-way media valve for coolant control
Specifications
- Operating fluid pressure: 0 to 3.5 MPa
- Fluid: Coolant
- Operation: External pilot solenoid/Air operated
- Operating fluid temperature: -5 to 50 degrees C
- Pilot air: Pressure
- Proof pressure: 5.5 MPa
- Ambient temperature: -5 to 50 degrees C
- Max. operating frequency: 20 times/min
- Mounting position: Vertical upwards
- Port size: 3/8
- Orifice diameter: 7.1 mm
- Flow characteristics Av: 46 x 10^-6 m^2
- Pilot port size: 1/8
- Mass: 2 kg
- Face-to-face dimension: 60 mm
- Type: High Pressure Coolant Valve
- Seal Material: NBR, FKM
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships Tomorrow
