SQUARE D FAL36015 3-POLE 15A CIRCUIT BREAKER
Quick Overview
Manufactured By: SQUARE D
Manufacturer Part Number: FAL36015
IMS Product Code: 1833075
Packaging: Sold Individually
Description:
Square D FAL36015 3-Pole 15A Circuit Breaker
3-Pole thermal-magnetic molded case circuit breaker with 15A current rating and 600V AC voltage rating. Features LI - long-time and instantaneous trip functions and lug terminals.
Specifications
- Amperage: 15
- Voltage: 600VAC
- Poles: 3
- Phase: 3
- Mounting Type: Unit
- Interrupting Rating: 18kAIC at 480V
- Connection Type: Feed-Thru
- Protection: Thermal Magnetic
- Functions: LI - Long-Time and Instantaneous Trip
- Terminal Connection: Line and Load Side Lug
- Length (in): 4.13
- Width (in): 4.5
- Height (in): 6.4
- Weight: 5.04 lbs
- Magnetic Hold Current: 275 A
- Tightening Torque: 45 lb-in
- Wire Size: 14 To 4 Awg (Copper) Or 12 To 4 Awg (Aluminum)
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 3 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
