SQUARE D FY14015C 1 POLE CIRCUIT BREAKER
Quick Overview
Manufactured By: SQUARE D
Manufacturer Part Number: FY14015C
IMS Product Code: 1781653
Packaging: Sold Individually
Description:
Square D FY14015C 1 Pole Circuit Breaker
1 Pole thermal magnetic molded case circuit breaker with 15A current rating and 277VAC/125VDC voltage rating. I-Line style plug-in connection. Long time and instantaneous trip functions.
Specifications
- Amperage: 15
- Voltage: 277VAC, 125VDC
- Poles: 1
- Phase: 1
- Mounting Type: Plug In
- Interrupting Rating: 14kAIC at 240V
- Connection Type: I-Line Style Plug-In
- Protection: Thermal Magnetic
- Functions: LI - Long-Time and Instantaneous Trip
- Length (in): 4.13
- Width (in): 1.5
- Height (in): 6.4
- Temperature Rating: 40 degrees C
- Max Wire Size: 4 AWG
- Min Wire Size: 14 AWG
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 2 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
