SUMITOMO CNHM05-6075YA-21 INLINE SPEED REDUCER
Quick Overview
Brand: SUMITOMO
Part Number: CNHM05-6075YA-21
IMS Product Code: 2150932
Packaging: Sold Individually
Description:
Sumitomo CNHM05-6075YA-21 Inline Speed Reducer - 21:1 Ratio, 3/4 in Output Shaft Diameter, Single Reduction, 1/2HP 230/460V
- Reducer Type: Inline
- Ratio: 21:1
- Output Shaft Diameter: 3/4 in
- Reduction: Single
- Manufacturer Reducer Size: 6075
- Housing Material: Cast Iron, Ductile Iron
- Maximum Output RPM, 83.300 @ 1750 rpm input: Maximum Output Torque, 385 in-lbs @ 1750 rpm
- Housing Dimensions: 5.67 x 3.31 x 5.59 in
- Max Input Horsepower: 0.500 hp @ 1750 rpm
- Overhung Load Capacity: 397 lb
- Standards Met: AGMA, CE, CSA, IEC, JIS, NEMA, UL
- Series: Cyclo 6000
- Housing Height: 5.59 in
- Housing Length: 5.67 in
- Housing Width: 3.31 in
- UPC_NO: 690825038472
- Weight: 17.00 lbs
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships today if ordered in the next 7 hours and 34 minutes.
