TECO WESTINGHOUSE HH0304 30 HP MOTOR
Quick Overview
Manufactured By: TECO WESTINGHOUSE
Manufacturer Part Number: HH0304
IMS Product Code: 2150521
Packaging: Sold Individually
Description:
Teco Westinghouse HH0304 30 HP Motor
Electric motor, 30 HP, 1800 RPM, 460V, 3-phase, TEFC enclosure, 286T frame.
Specifications
- Enclosure: TEFC
- Frame: 286T
- HP: 30
- Hz: 60
- Phase: 3
- RPM: 1800
- Voltage: 460
- Type: Electric Motor
- Efficiency: NEMA Premium Efficient
- Service Factor: 1.15
- Temperature Rise: Class B
- Insulation: Class F
- Weight: 656 lbs
- NEMA Design: NEMA Design B
- Ambient Temperature: 40 degrees C
- Elevation: 3300 ft
- Rotation: Bidirectional
- Frame Material: Cast Iron
- Shaft Material: 1045 Carbon Steel
- Rotor Construction: Aluminum Die Cast Squirrel Cage
- Paint System: 2 Part Epoxy
- Paint Color: Blue
- Bearings: Vacuum De-Gassed Re-Greasable Ball Bearings
- Grounding: Grounding Terminal Inside Main Box
- Nameplate: Stainless Steel Nameplate
- Drains: Stainless Steel Automatic Breather Drains
- Speed Range: 20:1 VT, 10:1 CT
- Vibration: 0.08 Inches per Second
- Noise Level: 85 dB(A) at 1 Meter Unloaded
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 12 minutes.
