THK HSR35C1SS(GK) LINEAR GUIDE BLOCK
Quick Overview
Manufactured By: THK
Manufacturer Part Number: HSR35C1SS(GK) BLOCK
IMS Product Code: 1994037
Packaging: Sold Individually
Description:
THK HSR35C1SS(GK) Linear Guide Block
THK HSR35C1SS(GK) BLOCK Standard Interchangeable Linear Guide Ball Carriage
Specifications
- Series: HSR-C
- Block Type: Standard Block
- Nominal Rail Size: 34 mm
- Static Load Capacity: 70.2 kN
- Dynamic Load Capacity: 53.9 kN
- Overall Height: 48 mm
- Overall Length: 109.40 mm
- Overall Width: 100 mm
- Seal Type: SS (end seal + side seal + inner seal)
- Grease Type: THK AFB-LF Grease
- Accuracy Class: Normal Grade
- Preload: Normal
- Bearing Material: Carbon Steel
- Weight: 1.6 kg
- Load Capacity: 70.2 kN
- Measurement Standard: Metric
- Assembly Dimension(s) (W1): 34mm �0.05mm
- Assembly Dimension(s) (W2): 33mm
- Assembly Dimension(s) (M): 48mm
- Assembly Dimension(s) (H3): 7.5mm
- Slide Unit Dimension(s) (W): 100mm
- Slide Unit Dimension(s) (L): 109.4mm
- Slide Unit Dimension(s) (L1): 80.4mm
- Slide Unit Dimension(s) (K): 40.5mm
- Slide Unit Dimension(s) (t): 21mm
- Slide Unit Dimension(s) (T): 12mm
- Slide Unit Dimension(s) (T1): 13mm
- Slide Unit Dimension(s) (N): 8mm
- Slide Unit Dimension(s) (E): 12mm
- Mounting Hole Dimension(s) (B): 82mm
- Mounting Hole Dimension(s) (C): 62mm
- Mounting Hole Size (4-S): M10
- Mounting Hole Depth (H): 8.5mm
- Pilot Hole for Grease Nipple Dimension(s) (e0): 5.5mm
- Pilot Hole for Grease Nipple Dimension(s) (f0): 5.6mm
- Pilot Hole for Grease Nipple Dimension(s) (D0): 5.2mm
- Grease Nipple: B-M6F
- Basic Dynamic Load Rating (C): 53.9kN
- Basic Static Load Rating (C0): 70.2kN
- Static Permissible Load - Single Block Assembly (MA): 0.895kN-m
- Static Permissible Load - Dual Block Assembly (MA): 4.51kN-m
- Static Permissible Load - Single Block Assembly (MB): 0.895kN-m
- Static Permissible Load - Dual Block Assembly (MB): 4.51kN-m
- Static Permissible Load - Dual Block Assembly (MC): 1.05kN-m
- Maximum Operating Temperature: +80�C
- Temperature resistance: -20 to +80 �C
- Material: Stainless Steel
- Size: HSR35
