THK HSR45A LINEAR MOTION GUIDE
Quick Overview
Manufactured By: THK
Manufacturer Part Number: HSR45A
IMS Product Code: 2150151
Variation: Unspecified
Unspecified
Type: Guide Block
Type: Rail
Packaging: Sold Individually
Description:
THK HSR45A Linear Motion Guide
Linear Motion Guide
Specifications
- Type of guide: 4-way Equal Load Type
- Loading method: Top surface mount
- Ball (roller) retainer: None
- Dust cover type: Steel tape
- Seal Resistance Value (N): 19.60
- Seal types for seal resistance value: UU
- Lubrication method: Grease lubrication, oil lubrication, other
- Grease brand: AFA, AFB-LF, AFC, AFE, AFF, AFG, Other, Antirust oil only
- Nipple, plumbing fixture type: A-PT1/8, B-PT1/8, C-PT1/8, LF-C, LF-D, SF-C, SF-D
- Preload grade: Normal (no symbol), light preload (C1), medium preload (C0)
- Accuracy Grades: Normal grade (No Symbol), high accuracy grade (H), precision grade (P), super precision grade (SP), ultra precision grade (UP)
- Type using standard material: Iron-based
- Standard grease: AFB-LF
- Standard grease nipples: B-PT1/8
- Standard seal: UU, SS
- Block surface treatment: AP-CF, AP-C, AP-HC, other
- Rail surface treatment: AP-CF, AP-C, AP-HC, other
- Rail mounting method: Bolt fixed
- Guide clamper: Yes
- Minimum service temperature(Centigrade°C): -15
- Maximum service temperature(Centigrade°C): 80
- Materials: Bearing steel
- Outer dimensions: 120 mm
- Block dimensions: 139 mm
- Rail dimensions: 100 mm
- Basic load rating: 82.2 kN
- Radial: 80 mm
- Height: M12
- Length: 105 mm
- Dynamic: 82.2 kN
- Static: 101 kN
- Rolling Element: Balls
- Block Type: A
- Overall(mm) Height M: 60
- Width W: 120
- Length L: 139
- Block(mm) B: 100
- C: 80
- T: 13
- Rail(mm) Pitch F: 105
- d1xd2xh: 14*20*17
- Basic load rating(Radial) Dynamic C (kN): 60
- Static C0 (kN): 95.6
- Block Weight(KG/EA): 2.8KG
- Rail weight(KG/m): 11KG
- Width (W): 120 mm
- Height(M): 60 mm
- Length(L): 139 mm
- LM block Weight: 1.6 kg
- LM Rail Weight: 6.6 kg/160L
- Dynamic rating(C): 37.3 kN
- Static rating(Co): 61.1 kN
- B: 100 mm
- S: M12
- L1: 98 mm
- t: 25 mm
- T1: 15 mm
- K: 50 mm
- N: 10 mm
- E: 16 mm
- Width (W1): 45 mm
- W2: 37.5 mm
- Height M1: 38 mm
- F: 105 mm
