THK LMK25 LINEAR BALL BEARING
Quick Overview
Manufactured By: THK
Manufacturer Part Number: LMK25
IMS Product Code: 2172286
Packaging: Sold Individually
Description:
THK LMK25 Linear Ball Bearing
Linear ball bearing
Specifications
- Ball rows: 6
- Inscribed bore diameter (dr): 25
- Tolerance: 0 -0.010
- Outer diameter (D): 40
- Tolerance: 0 -0.016
- Overall length (L): 59
- Flange diameter (D1): 62
- K: 50
- H: 8
- PCD: 51
- Mounting hole: 5.5�9.2�5.4
- Dynamic rating (C): 980
- Static rating (C0): 1570
- Mass: 300
- Inner (d) MM: 25
- Outer (D) MM: 40
- Width (B) MM: 59
- Inner (d) Inch: 0.9843
- Outer (D) Inch: 1.5748
- Width (B) Inch: 2.3228
- Weight (kg): 0.27
- Seal: No Seal
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships today if ordered in the next 15 hours and 1 minutes.
