THK SHS-25R LINEAR GUIDE BLOCK
Quick Overview
Manufactured By: THK
Manufacturer Part Number: SHS25R
IMS Product Code: 2036163
Packaging: Sold Individually
Description:
THK SHS-25R Linear Guide Block
4-way Equal Load Type Linear Guide Block with Top Surface Mount and Ball Retainer, made of Iron-based material.
Specifications
- Overall Height M: 40 mm
- Width W: 48 mm
- Length L: 92 mm
- Block B: 35 mm
- C: 35 mm
- S: M6x8
- T: 8 mm
- Rail Pitch F: 60 mm
- d1xd2xh: 7*11*9
- Basic Load Rating (Radial) Dynamic C: 31.7 kN
- Static C0: 52.4 kN
- Seal Resistance Value: 10.50 N
- Minimum Service Temperature: -15 degrees C
- Maximum Service Temperature: 80 degrees C
- Preload Grade: Normal (no symbol), Light Preload (C1), Medium Preload (C0)
- Accuracy Grades: Normal grade (No Symbol), High accuracy grade (H), Precision grade (P), Super precision grade (SP), Ultra precision grade (UP)
- Lubrication Method: Grease lubrication, oil lubrication
- Rail Mounting Method: Bolt fixed
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships today if ordered in the next 11 hours and 3 minutes.
New - Missing Box (Special):
This item comes with two bags of accessories.
Availability: 1 In Stock
Ships today if ordered in the next 10 hours and 3 minutes.
