THK SL16UU LINEAR BUSHING
Quick Overview
Manufactured By: THK
Manufacturer Part Number: SL16UU
IMS Product Code: 2171262
Packaging: Sold Individually
Description:
THK SL16UU Linear Bushing
Linear bushing for linear motion applications
Specifications
- Basic load rating Dynamic rating C: 1230 N
- Static rating C0: 2350 N
- Mass: 403 g
- Height M: 36 mm
- Width W: 60 mm
- Length L: 85 mm
- Mounting hole position Tap S � l: M5�12
- Through bolt S2: M4
- Center height J: 19 mm
- W1: 25 mm
- K: 35 mm
- W2: 46 mm
- T: 9 mm
- Inscribed bore diameter dr: 16 mm
- Tolerance: 0 -0.009
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships today if ordered in the next 9 hours and 29 minutes.
