TIMKEN 5209K ANGULAR CONTACT BEARING
Quick Overview
Manufactured By: TIMKEN
Manufacturer Part Number: 5209K
IMS Product Code: 1865144
Packaging: Sold Individually
Description:
Timken 5209K Angular Contact Bearing
Double Row Angular Contact Bearing - 45 mm Bore, 85 mm OD, 1.1875 in Width, Open, 20 degrees Contact Angle, C0
Specifications
- Bore Type: Straight
- Bore Diameter: 45 mm
- Outside Diameter: 85 mm
- Overall Width: 1.1875 in
- Row Type: Double-Row Non-Fill Slot
- Closure Type: Open
- Snap Ring Included: Without Snap Ring
- Bearing Type: Angular Contact Bearings
- Contact Angle: 20 degrees
- Internal Clearance: C0
- Radial Dynamic Load Capacity: 12900 lbf
- Radial Static Load Capacity: 8800 lbf
- Cage Material: Steel
- Max Rpm: 4620 rpm
- Finish Coating: Uncoated
- Precision Rating: Not Rated
- Fillet Radius: 1 mm
- Series: 5200
- Weight: 1.56 lbs
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 24 In Stock
Ships today if ordered in the next 11 hours and 27 minutes.
