TIMKEN LM451349-20025 TAPERED ROLLER BEARING CONE
Quick Overview
Manufactured By: TIMKEN
Manufacturer Part Number: LM451349-20025
IMS Product Code: 2145849
Packaging: Sold Individually
Description:
Timken LM451349-20025 Tapered Roller Bearing Cone
Tapered roller bearing cone with 10.5 inch bore and 2.25 inch width, made of chrome steel.
Specifications
- Bore Diameter: 10.5000 in
- Overall Width: 2.2500 in
- Bearing Material: Chrome Steel
- Abma Precision Rating: Class 2
- Cage Material: Steel
- Inner Ring Width: 2-1/4 in
- Operating Temperature Range: -65 to +250 degrees F
- Finish Coating: Uncoated
- Series: LM451300
- Compatible Cup: LM451310, LM451310B
- Weight: 23.19 lbs
- Cone Width: 2-1/4 in
- Load Capacity: 167000 lb Dynamic/339000 lb Static
- Maximum Shaft Fillet Radius: 0.14 in
- Inside Diameter: 10-1/2 in
- Measurement System: Imperial
- Inner (d) MM: 266.7
- Width (B) MM: 57.15
- Weight (kg): 10.96
