TRITAN SBLF204-12G FLANGE BEARING UNIT
Quick Overview
Manufactured By: TRITAN
Manufacturer Part Number: SBLF204-12G
IMS Product Code: 2162083
Packaging: Sold Individually
Description:
Tritan SBLF204-12G Flange Bearing Unit
2-bolt flange mounted bearing unit with 0.75 inch bore, cast iron housing, and radial ball bearing insert.
Specifications
- Bearing Insert Type: Radial Ball
- Number of Mount Holes: 2
- Housing Material: Cast Iron
- Bearing Insert Material: Alloy Steel
- Shaft Locking Type: Set Screws
- Bore Diameter: 0.75 in
- Overall Length: 3-35/64 in
- Overall Width: 1-5/32 in
- Overall Height: 2-25/64 in
- Flange Thickness: 7/16 in
- Mount Hole Center-to-Center Length: 2-13/16 in
- Mounting Bolt Size: 5/16 in
- Closure: Double Sealed
- Seal Material: Rubber
- Lubrication Openings: One Zirc Fitting
- Lubricant Material: NLGI #2 Equivalent
- Maximum Temperature: 250 degrees F
- Minimum Temperature: -40 degrees F
- Static Radial Load Capacity: 1,494 lbf
- Dynamic Load Capacity: 2,877 lbf
