TURCK BI3U-MT12-AP6X-H1141 INDUCTIVE SENSOR
Quick Overview
Manufactured By: TURCK
Manufacturer Part Number: BI3U-MT12-AP6X-H1141
IMS Product Code: 2039554
Packaging: Sold Individually
Description:
Turck BI3U-MT12-AP6X-H1141 Inductive Sensor
Threaded barrel inductive sensor with PNP output and M12 connector
Specifications
- Design: Threaded barrel
- Construction size: M12 x 1
- Rated switching distance: 3 mm
- Mounting: Flush
- Operating voltage: 10…30 VDC
- Output function: NO contact, PNP
- Switching frequency: 3.0 kHz
- Electrical connection: Connector, M12 × 1
- Housing material: Metal, CuZn, PTFE-coated
- Ambient temperature: -30…+85 °C
- Protection class: IP68
- Special features: uprox+, Factor 1, Resistant to magnetic fields, PTFE-coated
- Diameter: 12 mm
- Shielding: Shielded
- Power Type: DC
- Range: 3 mm
- Output Type: NO PNP
- Number of Wires: 3
- Composition: Metallic
- Voltage: 10-30 VDC
- Nominal Voltage: 12 VDC, 24 VDC
- Sensing Type: End
- Status Indicator: Yes
- Short Circuit Protection: Yes
- Reverse Polarity Protection: Yes
- Max Load Current: 0.2 A
- Height: 52 mm
- Length: 12 mm
- Thread Size: M12
- Current Rating: 200 mA
- Max Operating Temperature: 85 °C
- Max Supply Voltage: 30 V
- Min Operating Temperature: -30 °C
- Min Supply Voltage: 10 V
- Sensing Distance: 3 mm
- Termination: Connector
- RoHS: Compliant
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
