VON DUPRIN 35A-NLOP 313AN 3 RIM EXIT DEVICE
Quick Overview
Manufactured By: VON DUPRIN
Manufacturer Part Number: 35A-NLOP 313AN 3
IMS Product Code: 1981613
Packaging: Sold Individually
Description:
Von Duprin 35A-NLOP 313AN 3 Rim Exit Device
Rim exit device with night latch for single and double doors
Specifications
- Device Lengths: 3' 2'4" to 3' (711mm to 914 mm) door size; 4' 2'10" to 4' (864 mm to 1219 mm) door size
- Dogging Feature: Hex key dogging standard
- Latch Bolt: Deadlocking, 3/4" (19mm) throw
- Device Centerline from Finished Floor: 39 13/16" (1011 mm); 39 11/16" (1008 mm) with Mullion
- Center Case Dimensions: 8 3/16" x 2 13/32" x 1 9|16" (208mm x 62mm x 40mm)
- Mechanism Case Dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
- Projection: Pushbar Neutral � 3 13/16" (97 mm); Pushbar Depressed � 3 1/16" (78 mm)
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 5 hours and 27 minutes.
