WEG 02018EP3ER256TC 20HP TEFC MOTOR
Quick Overview
Manufactured By: WEG
Manufacturer Part Number: 02018EP3ER256TC
IMS Product Code: 2120899
Packaging: Sold Individually
Description:
Weg 02018EP3ER256TC 20HP TEFC Motor
20 HP, 1800 RPM, 208/230/460 Volts, TEFC, 256TC, Footless
Specifications
- Enclosure: TEFC
- Frame: 256TC
- HP: 20
- Hz: 60
- RPM: 1760
- Voltage: 208-230/460V
- Output: 20 HP
- Poles: 4
- Frequency: 60 Hz
- Torque: 58.9 lb. ft
- Full Load Amps: 48.6/24.3 A
- Efficiency (100%): 91.0
- Power factor (100%): 0.85
- Insulation: F
- Noise: 64 dB(A)
- No load current: 18.0/9.00 A
- Locked rotor current (II/In): 6.0
- Service Factor: 1
- Weight: 296 lbs
- Phase: 3
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 26 minutes.
