YASKAWA CIMR-AU4A0088AAA AC DRIVE
Quick Overview
Manufactured By: YASKAWA
Manufacturer Part Number: CIMR-AU4A0088AAA
IMS Product Code: 2154703
Packaging: Sold Individually
Description:
Yaskawa CIMR-AU4A0088AAA AC Drive
Three-phase AC Drive with adjustable frequency/vector control for crane applications
Specifications
- Brand: Yaskawa
- Type: General Purpose AC Drive
- Maximum Load: 60 HP
- Input Voltage: 380-480 V
- Current Rating: 88A/75A
- Input Type: 3-phase
- Weight: 80 lbs
- Network Frequency (Output): 0.01-400 Hz
- Network Frequency (Input): 50/60 Hz
- Display: LED 5-digit
- Protection Functions: Motor overheat, Overcurrent, Overload, Overvoltage, Undervoltage, Momentary power loss ride-thru, Overheat, Ground fault
- Communication Protocol: RS-422, RS-485
- Mounting Mode: Wall mounting
- Degree of Protection: IP00
- Dimensions: 329 mm x 501.5 mm x 256.75 mm
- Ambient Air Temperature for Storage: -20 to 60 degrees C
- Technology: Forced ventilation (Fan-cooling), Standard heatsink fins, Integrated DC choke
- Rated Apparent Power: 67 kVA (Normal duty), 57 kVA (Heavy duty)
- Application: HVAC, Fans, Pumps, Compressors, Conveyors, Machine Tools, Extruders, Punching Presses, Winders
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships today if ordered in the next 15 hours and 21 minutes.
