BROWNING R1 3 SPLIT TAPER BUSHING
Quick Overview
Manufactured By: BROWNING
Manufacturer Part Number: R1 3
IMS Product Code: 2129548
Packaging: Sold Individually
Description:
Browning R1 3 Split Taper Bushing
Steel split taper bushing with 3 inch bore and solid flange
Specifications
- Bushing Size: R1
- Bore Type: Finished Bore
- Keyway Size: 3/4 x 3/8
- Bore Diameter: 3 in
- Material: Steel
- Flange Outside Diameter: 5.3750 in
- Flange Thickness: 5/8 in
- Flange Type: Solid Flange
- Length Through Bore: 2.8750 in
- Barrel Diameter Large End: 4 in
- Screw Torque: 348 in
- Barrel Diameter Small End: 3-7/8 in
- Bolt Circle Diameter: 4-5/8 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 3/8 in
- Screw Length: 1-3/4 in
- Mounting Type: Conventional
- Weight: 5.94
