BROWNING VF4S-227 FLANGE BLOCK BEARING
Quick Overview
Manufactured By: BROWNING
Manufacturer Part Number: VF4S-227
IMS Product Code: 2053090
Packaging: Sold Individually
Description:
Browning VF4S-227 Flange Block Bearing
Four bolt flange mounted ball bearing with 1.6875-inch bore diameter, cast iron housing, and 52100 bearing steel insert with setscrew lock.
Specifications
- Bore Diameter: 1.6875 in
- Bore Shape: Straight
- Bearing Insert Material: 52100 Bearing Steel
- Bearing Type: Standard Duty
- Cage Material: Molded fiber glass reinforced nylon
- Cage Type: Ball Riding Retainer
- Dynamic Load Rating: 7,370 lb
- Housing Color: Black
- Housing Construction: One Piece
- Housing Material: Cast Iron
- Housing Type: Flange, Four Bolt
- Inner Race Heat Treat Method: Zone-Hardened
- Insert: VS-227
- Lubricant: Lithium Complex NLGI 2 Grease
- Maximum Operating Temperature: 225 F
- Maximum Speed: 3,000 rpm
- Radial Clearance: C3 Standard
- Rolling Element: Ball Bearing
- Seal Type: Single Lip Contact Seal with Flinger
- Setscrew Torque: 165 in/lbs
- Shaft Locking Type: Set Screw
- Static Load Rating: 4,590 lb
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships today if ordered in the next 5 hours and 43 minutes.
