FAG 234432-M-SP ANGULAR CONTACT THRUST BALL BEARING
Quick Overview
Manufactured By: FAG
Manufacturer Part Number: 234432-M-SP
IMS Product Code: 2161081
Packaging: Sold Individually
Description:
Fag 234432-M-SP Angular Contact Thrust Ball Bearing
Double-direction axial angular contact ball bearing with brass cage, 160mm bore diameter, 240mm outside diameter, 96mm width, 60-degree contact angle, and super precision rating.
Specifications
- Inside Diameter: 160 mm
- Outside Diameter: 240 mm
- Width: 96 mm
- Cage Type: Brass
- Seals Or Shields: Open Type
- Dynamic Load Rating: 168 kN
- Static Load Rating: 600 kN
- Fatigue Load Rating: 38 kN
- Reference Speed Rating: 3400 r/min
- Limiting Speed Rating: 2400 r/min
- Bore Type: Straight
- Contact Angle: 60 degrees
- Bearing Material: 52100 Steel
- Radial Dynamic Load Capacity: 168000 N
- Radial Static Load Capacity: 600000 N
- Operating Temperature: -30 to +150 degrees C
- Limiting Speed (Oil): 3400 rpm
- Tolerance Class: SP
- Precision Class: Special Precision
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 5 hours and 34 minutes.
