FAG B71940-E-T-P4S-UL ANGULAR CONTACT BALL BEARING
Quick Overview
Manufactured By: FAG
Manufacturer Part Number: B71940-E-T-P4S-UL
IMS Product Code: 2126736
Packaging: Sold Individually
Description:
Fag B71940-E-T-P4S-UL Angular Contact Ball Bearing
200 mm Bore, 280 mm OD, 38 mm Width, 25 degrees Contact, Open
Specifications
- Bore Type: Straight
- Bore Diameter: 200 mm
- Outside Diameter: 280 mm
- Overall Width: 38 mm
- Closure Type: Open
- Contact Angle: 25 degrees
- Internal Clearance: C0
- Precision Rating: ABEC 7 (ISO Class 4), ABEC 9 (ISO Class 2)
- Operating Temperature Range: -30 to +100 degrees C
- Radial Dynamic Load Capacity: 193 kN
- Bearing Type: Spindle & Precision Machine Tool Angular Contact Bearings
- Radial Static Load Capacity: 240 kN
- Bearing Material: Steel (Balls)
- Max Rpm: 5300 rpm
- Cage Material: Phenolic Resin
- Finish Coating: Uncoated
- Fillet Radius: 1 mm
- Series: 719
