FESTO DSR-25-180-P SEMI-ROTARY DRIVE
Quick Overview
Manufactured By: FESTO
Manufacturer Part Number: DSR-25-180-P
IMS Product Code: 2126761
Packaging: Sold Individually
Description:
Festo DSR-25-180-P Semi-Rotary Drive
25mm rotary vane actuator with Spigot shaft, 180° adjustable swivel angle, and elastic cushioning.
Specifications
- Size: 25
- Swivel Angle: 180°
- Cushioning Angle: 1.8°
- Rotation Angle Adjustment Range: 0 DEG to 180 DEG
- Cushioning: Elastic cushioning rings/plates at both ends
- Mode of Operation: Double-acting
- Design: Vane design
- Position Detection: Without position detection
- Max Swivel Frequency: 3 HZ at 0.6 MPa (6 bar, 87 psi)
- Operating Medium: Compressed air to ISO 8573-1:2010 [7:-:-]
- Theoretical Torque: 5 NM at 0.6 MPa (6 bar, 87 psi)
- Product Weight: 584 g
- Mounting Type: Through-hole
- Drive Shaft Material: Steel
- Drive Shaft Finish: Nickel-plated
- Seal Material: NBR
- Operating Pressure: 1.5 bar to 8 bar
- Ambient Temperature: -10 °C to 60 °C
- Pneumatic Connection: M5
- Length: 94.5 mm
- Width: 98 mm
- Height: 68 mm
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 1 minutes.
