FYH UCF205J 4-BOLT FLANGE MOUNTED BEARING
Quick Overview
Manufactured By: FYH, INC.
Manufacturer Part Number: UCF205J
IMS Product Code: 2166714
Packaging: Sold Individually
Description:
FYH UCF205J 4-Bolt Flange Mounted Bearing
Four-bolt flange mounted bearing unit with set screw locking, 25mm inner diameter, heavy-duty design for precise alignment and robust performance.
Specifications
- Bore: 25 mm
- Shaft: 25 mm
- Locking: set screw
- Bolt size: M10 (3/8 in)
- Basic load Cr: 14 kN
- Cor: 7.85 kN
- Bearing: UC205
- Grease fitting: 28UNF
- L: 95 mm
- A: 27 mm
- J: 70 mm
- A0: 35.8 mm
- B: 34.1 mm
- S: 14.3 mm
- N: 12 mm
- A1: 13 mm
- A2: 16 mm
- Housing Number: F205
- Seal: 2F - Standard Seal for Y-bearings
- Lubrication: Standard Lubrication
