INA DRS40115 SEAL CARRIER ASSEMBLY
Quick Overview
Manufactured By: INA
Manufacturer Part Number: DRS40115
IMS Product Code: 1905544
Packaging: Sold Individually
Description:
INA DRS40115 Seal Carrier Assembly
Seal carrier assembly with integral rotary shaft seal, 78 mm shaft diameter, 115 mm outer diameter, 27.5 mm width, 90 degree offset, 4 holes, -30 to 120 degrees C temperature rating.
Specifications
- Series: DRS Series
- Shaft Diameter: 78 mm
- Outer Diameter: 115 mm
- Width: 27.5 mm
- Offset Angle: 90 degrees
- Number of Holes: 4
- Temperature Rating: -30 to 120 degrees C
- Weight: 690 g
- Pitch Circle Diameter (Holes): 106 mm
- Outside Diameter Seal: 100 mm
- Screw Size: M3X35
- Inner Diameter Centering Seal Lip: 78 mm
- Width Seal: 10 mm
- Number of Screws: 4
- Inner Diameter Centering: 78 mm
- Width Wave Carrier: 27.5 mm
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 45 minutes.
