INA ZKLN-20522RS THRUST BEARING ANGULAR CONTACT DOUBLE ROW
Quick Overview
Manufactured By: INA
Manufacturer Part Number: ZKLN-20522RS
IMS Product Code: 1733785
Packaging: Sold Individually
Description:
| Bore Diameter: | 20 mm |
| Outside Diameter: | 52 mm |
| Overall Width: | 28 mm |
| Thrust Bearing Type: | Double-Direction |
| Outside Diameter Design: | Straight |
| Precision Rating: | ABEC 7 (ISO Class 4) |
| Static Load Capacity: | 10600 lbf |
| Dynamic Load Capacity: | 5800 lbf |
| Operating Temperature Range: | -30 to +120 °C |
| Maximum RPM: | 3000 RPM |
| Cage Material: | Plastic |
| Application: | Ball Screw Support |
| Series: | ZKLN |
| Standards Met: | DIN 620 |
Request A Quote
Let us know your requirements and an IMS Supply representative will provide you with a detailed quote.
Shipping Times Provided In Quote
