KAYDON KD050AR0 THIN SECTION BALL BEARING
Quick Overview
Manufactured By: KAYDON BEARING
Manufacturer Part Number: KD050AR0
IMS Product Code: 2144837
Packaging: Sold Individually
Description:
Kaydon KD050AR0 Thin Section Ball Bearing
Thin section angular contact ball bearing with 5 inch bore diameter, 6 inch outside diameter, and 0.5 inch width.
Specifications
- Bore Type: Straight
- Bore Diameter: 5.0000 in
- Outside Diameter: 6.0000 in
- Overall Width: 0.5000 in
- Closure Type: Open
- Operating Temperature Range: -65 to +250 F
- Internal Clearance: C0
- Radial Dynamic Load Capacity: 2040 lbf
- Bearing Material: Steel
- Precision Rating: ABEC 1 (ISO Class Normal)
- Ball Retainer Material: Brass
- Contact Angle: 30 degrees
- Weight: 0.98 lbs
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
