NACHI 6017C3 DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NACHI
Manufacturer Part Number: 6017C3
IMS Product Code: 1867396
Packaging: Sold Individually
Description:
Nachi 6017C3 Deep Groove Ball Bearing
Single row, deep groove ball bearing made of steel with an open bore and cylindrical clearance C3. It is designed for high-load rotary applications.
Specifications
- Bore Type: Cylindrical
- Cage Material: JIS SPCC Steel/Stamped Steel
- Closure Type: Open
- Contact Angle (Deg): N/A
- Dynamic Load Capacity (N): 49500
- Inner Diameter (ID/mm): 85 mm
- Internal Clearance: C3
- ISO Precision Class: P0
- Limiting Speed - Grease/Oil (RPM): 5000/6000
- Max Operating Temp.: 120�C/248�F
- Number of Rows: 1
- Outer Diameter (OD/mm): 130 mm
- Preload: N/A
- Rolling Element/Bearing Material: JIS SUJ2 Steel/Steel
- Seals or Shields/Snap Ring: No
- Series: 6000
- Static Load Capacity (N): 43000
- Universally (Flush) Ground: N/A
- Width/mm: 22 mm
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 9 hours and 2 minutes.
