NACHI NN3016 CYLINDRICAL ROLLER BEARING
Quick Overview
Manufactured By: NACHI
Manufacturer Part Number: NN3016
IMS Product Code: 2164848
Packaging: Sold Individually
Description:
Nachi NN3016 Cylindrical Roller Bearing
Double-row, super-precision cylindrical roller bearing with dimensions 80 mm x 125 mm x 34 mm
Specifications
- Bore Dia: 80 mm
- Outside Dia: 125 mm
- Width: 34 mm
- Type: NN
- Seal: Open
- Fillet Radius - ra max: 1 mm
- Bore Type: Cylindrical
- Tolerance class: P5 (ABEC-5)
- Radial dynamic load rating: 146.497 kN
- Radial static load rating: 184.87 kN
- Grease rpm: 4728 r/min
- Oil rpm: 5909 r/min
- Abutment Dimensions Shaft - da min: 86.5 mm
- Abutment Dimensions Housing - Da max: 118.5 mm
- Dimension Chamfer - r min: 1.1 mm
- Raceway diameter of outer ring - EW: 113 mm
- Rolling Element Material: GCr15SiMn
- Inner/Outer Ring Material: GCr15SiMn
- Load Type: radial
- Rows NO.: Two
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 2 minutes.
