NSK NN3026MBKRE44CC1P4 CYLINDRICAL ROLLER BEARING
Quick Overview
Manufactured By: NSK
Manufacturer Part Number: NN3026MBKRE44CC1P4
IMS Product Code: 2160955
Packaging: Sold Individually
Description:
NSK NN3026MBKRE44CC1P4 Cylindrical Roller Bearing
NN-type double-row cylindrical roller bearing with a 130 mm bore. It features a pressed steel cage (CC) and P4 precision class. This bearing carries high radial loads at moderate to high speeds in gearboxes, generators, and rolling-mill drives. Backed by NSK's precision-bearing engineering heritage.
Specifications
- Bearing Type: NN: Inner ring rib type
- d: 130 mm
- D: 200 mm
- B: 52 mm
- r(min.): 2 mm
- Cr: 325 kN
- C0r: 475 kN
- Grease: 4600 min-1
- Oil (Oil-air): 5500 min-1
- Ew: 182 mm
- s: 2.4 mm
- da(min.): 139 mm
- d1a(min.): 141 mm
- Da(min.): 185 mm
- Da(max.): 191 mm
- ra(max.): 2 mm
- CC1(max.): 35 �m
- CC1(min.): 10 �m
- CC0(max.): 40 �m
- CC0(min.): 25 �m
- CC9(max.): 30 �m
- CC9(min.): 15 �m
- Recommended Grease Quantities: 18 g/brg
- dh: 4 mm
- W: 8 mm
- m: 4
- Mass(approx.): 5.53 kg
- Accuracy: P4: ISO Class 4
- Bore Type: Straight
- Rows: 2
- Internal Clearance: cc1
- Limiting Speed: 4600
- Dynamic Load: 284000
- Static Load: 475000
- Cage Material: brass
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 4 hours and 43 minutes.
