NTN NN3010KC1NAP4 DOUBLE ROW CYLINDRICAL ROLLER BEARING
Quick Overview
Manufactured By: NTN BEARING
Manufacturer Part Number: NN3010KC1NAP4
IMS Product Code: 1907993
Packaging: Sold Individually
Description:
Ntn NN3010KC1NAP4 Double Row Cylindrical Roller Bearing
Double row cylindrical roller bearing with tapered bore, type NN. Features high strength machined brass cage and hardened alloy steel construction. Open enclosure, ISO Class 4 precision.
Specifications
- Type: Cylindrical Roller Bearing
- Bore Type: Tapered
- Material: Hardened Alloy Steel
- Cage Material: High Strength 2 piece Machined Brass
- Limiting Speed - Oil: 9400 RPM
- Limiting Speed - Grease: 8000 RPM
- Taper: 1:12
- Precision: ISO Class 4
- Configuration: Two
- Radial Internal Clearance: C1NA
- Static Load Rating: 72500 N
- Dynamic Load Rating: 53000 N
- Enclosure: Open
- Weight: 0.410 kg
- Operating Temperature Range: -40 to 120 degrees C
- d: 50.000 mm
- D: 80.000 mm
- B: 23.000 mm
- C: 23.000 mm
- Ew: 72.500 mm
- r: 1.000 mm
- da min: 55.000 mm
- db min: 57.000 mm
- Da max: 74.000 mm
- Db min: 74.000 mm
- Db max: 75.000 mm
- ras max: 1.000 mm
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 1 hours and 1 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 1 minutes.
