NTN 51216 THRUST BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 51216
IMS Product Code: 1956497
Packaging: Sold Individually
Description:
NTN 51216 Thrust Ball Bearing
Single Direction Thrust Ball Bearing designed to support axial loads in one direction. Features two grooved raceways and precision balls for low friction and smooth operation.
Specifications
- Type: Thrust Ball Bearing
- Bore Type: Round
- Outside Ring Type: Straight
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Oil: 2400 RPM
- Limiting Speed - Grease: 1700 RPM
- Precision: ISO Class 0
- Configuration: One
- Radial Internal Clearance: CN
- Static Load Rating: 218000 N
- Dynamic Load Rating: 78500 N
- Enclosure: Open
- Weight: 0.91 kg
- Operating Temperature Range: -40 to 120 degrees C
- d: 80 mm
- D: 115 mm
- T: 28 mm
- r: 1 mm
