NTN 562020/GNP4 DOUBLE DIRECTION ANGULAR CONTACT THRUST BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 562020/GNP4
IMS Product Code: 2156892
Packaging: Sold Individually
Description:
NTN 562020/GNP4 Double Direction Angular Contact Thrust Ball Bearing
Double Direction Angular Contact Thrust Ball Bearing with 100 mm bore diameter, 150 mm outside diameter, and 60 mm width. Made of High Carbon Chrome Steel with machined brass cage.
Specifications
- Type: Thrust Ball Bearing
- Bore Type: Round
- Outside Ring Type: Straight
- Material: High Carbon Chrome Steel
- Cage Type: Machined
- Cage Material: Brass
- Ball Material: Steel
- Limiting Speed - Oil: 3800 RPM
- Limiting Speed - Grease: 2900 RPM
- Precision: ISO Class 4
- Configuration: Two
- Static Load Rating: 51481 lbf
- Dynamic Load Rating: 15399 lbf
- Enclosure: Open
- Weight: 7.321 lb
- Operating Temperature Range: -40 to 250 F
- d: 3.9370 in
- D: 5.9055 in
- C: 1.1811 in
- T1: 2.3622 in
- J: 5.2362 in
- Ew: 5.3937 in
- r: 0.0591 in
- r1: 0.0394 in
- Wo: 0.3150 in
- do: 0.1575 in
- Contact Angle: 60
- da min: 4.6850 in
- Da max: 4.6850 in
- ras max: 0.0591 in
- r1as max: 0.0394 in
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
