NTN 7209 ANGULAR CONTACT BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 7209
IMS Product Code: 1992976
Packaging: Sold Individually
Description:
NTN 7209 Angular Contact Ball Bearing
Angular contact ball bearing
Specifications
- Type: Angular Contact Ball Bearing
- Bore Type: Round
- Material: High Carbon Chrome Steel
- Cage Type: Pressed
- Cage Material: Steel
- Ball Material: Steel
- Limiting Speed - Oil: 12000 RPM
- Limiting Speed - Grease: 8700 RPM
- Precision: ISO Class 0
- Configuration: One
- Radial Internal Clearance: CN
- Static Load Rating: 28700 N/28.70 kN
- Dynamic Load Rating: 39500 N/39.50 kN
- Enclosure: Open
- Weight: 0.410 kg
- Operating Temperature Range: -40 to 120 degrees C
- d: 45.000 mm
- D: 85.000 mm
- B: 19.000 mm
- r: 1.100 mm
- r1: 0.600 mm
- Contact Angle: 30 degrees
- a (Load Center): 28.500 mm
- da min: 52.000 mm
- db min: 49.500 mm
- Da max: 78.000 mm
- Db max: 80.500 mm
- ras max: 1.000 mm
- r1as max: 0.600 mm
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships today if ordered in the next 8 hours and 42 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 3 In Stock
Ships today if ordered in the next 9 hours and 42 minutes.
