NTN NKX35T2 NEEDLE ROLLER BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: NKX35T2
IMS Product Code: 1922516
Packaging: Sold Individually
Description:
NTN NKX35T2 Needle Roller Bearing
Needle Roller/Axial Ball Bearings combine the benefits of needle rollers and ball bearings to handle both radial and axial loads efficiently. With a compact design, it is well-suited for applications with limited space.
Specifications
- Type: Complex Bearing
- Bore Type: Round
- Configuration: One
- Clearance: CN
- Material: High Carbon Chrome Steel
- Cage Material: Nylon
- Limiting Speed - Oil: 5600 RPM
- Limiting Speed - Grease: 3900 RPM
- Precision: ISO Class 0
- Enclosure: Open
- Axial Static Load Rating: 10000 lbf, 44500 N
- Axial Dynamic Load Rating: 4600 lbf, 20400 N
- Radial Static Load Rating: 8100 lbf, 36000 N
- Radial Dynamic Load Rating: 4500 lbf, 20000 N
- Weight: 0.368 lb, 0.167 kg
- Operating Temperature Range: -40 to 250 ºF, -40 to 120 ºC
- Fw: 1.3780 in, 35.000 mm
- Fw Tolerance: 0.075/0.050 mm
- dw: 1.3780 in, 35.000 mm
- dw Tolerance: 0.041/0.025 mm
- D: 1.8504 in, 47.000 mm
- D1: 2.0472 in, 52.000 mm
- C: 1.1811 in, 30.000 mm
- C Tolerance: 0/-0.250 mm
- C1: 0.4724 in, 12.000 mm
- C1 Tolerance: 0/-0.200 mm
- C2: 0.3543 in, 9.000 mm
- r: 0.0236 in, 0.600 mm
- da min: 1.7717 in, 45.000 mm
- ras max: 0.0024 in, 0.060 mm
- Inside Diameter: 35 mm
- Outside Diameter: 47 mm
- Width: 30 mm
