NTN NN3010KC1NAP5 CYLINDRICAL ROLLER BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: NN3010KC1NAP5
IMS Product Code: 2144701
Packaging: Sold Individually
Description:
NTN NN3010KC1NAP5 Cylindrical Roller Bearing
Double Row Cylindrical Roller Bearing w/ Tapered Bore - Type NN
Specifications
- Bore Type: Tapered
- Material: Hardened Alloy Steel
- Cage Material: High Strength 2 piece Machined Brass
- Limiting Speed - Oil: 9400 RPM
- Limiting Speed - Grease: 8000 RPM
- Taper: 1:12
- Precision: ISO Class 5
- Configuration: Two
- Oil Hole: w/o Oil Hole
- Radial Internal Clearance: C1NA
- Static Load Rating: 16299 lbf, 72500 N
- Dynamic Load Rating: 11915 lbf, 53000 N
- Enclosure: Open
- Weight: 0.904 lb, 0.410 kg
- Operating Temperature Range: -40 to 250 ºF, -40 to 120 ºC
- d: 1.9690 in, 50.000 mm
- D: 3.1496 in, 80.000 mm
- B: 0.9055 in, 23.000 mm
- C: 0.9055 in, 23.000 mm
- Ew: 2.8543 in, 72.500 mm
- r: 0.0394 in, 1.000 mm
- da min: 2.1654 in, 55.000 mm
- db min: 2.2441 in, 57.000 mm
- Da max: 2.9134 in, 74.000 mm
- Db min: 2.9134 in, 74.000 mm
- Db max: 2.9528 in, 75.000 mm
- ras max: 0.0394 in, 1.000 mm
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships today if ordered in the next 13 hours and 41 minutes.
