NTN UC206 INSERT BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: UC206
IMS Product Code: 2166706
Packaging: Sold Individually
Description:
NTN UC206 Insert Bearing
Insert bearing with set screw and wide inner ring.
Specifications
- Type: Insert Bearing
- Bore Type: Round
- Bearing Type: Ball Bearing
- Material: Through Hardened Steel
- Limiting Speed - Grease: 4900 RPM
- Seal Type: Contact
- Seal Material: Nitrile Rubber
- Locking Device: Set Screw
- Lubrication: Non-Relubricatable
- Static Load Rating: 2540 lbf, 11300 N, 11.30 kN
- Dynamic Load Rating: 4400 lbf, 19500 N, 19.50 kN
- Enclosure: Double Sealed
- Weight: 0.717 lb, 0.325 kg
- d: 1.1811 in, 30 mm
- D: 2.4409 in, 62 mm
- C: 0.7480 in, 19 mm
- B: 1.5000 in, 38.100 mm
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
