POWEREX LS411460 DIODE MODULE
Quick Overview
Manufactured By: POWEREX
Manufacturer Part Number: LS411460
IMS Product Code: 1807644
Packaging: Sold Individually
Description:
Powerex LS411460 Diode Module
Single Rectifier Diode Module, 600A, 1400V
Specifications
- Average Rectified Current: 600 A
- Circuit Configuration: Single Diode
- Current - Average Rectified (Io): 600A
- Diode Type: Standard
- Element Configuration: Single
- Forward Current: 600 A
- Forward Voltage: 1.24 V
- Max Forward Surge Current (Ifsm): 31.5 kA
- Max Operating Temperature: 150 degrees C
- Max Repetitive Reverse Voltage (Vrrm): 1.4 kV
- Min Operating Temperature: -40 degrees C
- Mounting Type: Chassis Mount
- Number of Elements: 1
- Number of Terminals: 2
- Package / Case: POW-R-BLOK Module
- Reverse Standoff Voltage: 1.4 kV
- Speed: Standard Recovery >500ns, > 200mA (Io)
- Style: General Purpose
- Type: Diode Module
- Voltage - DC Reverse (Vr) (Max): 1400V
- Voltage - Forward (Vf) (Max) @ If: 1.19V @ 1800A
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships Tomorrow
