SKF NN3017KTN9/SPW33 CYLINDRICAL ROLLER BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: NN3017KTN9/SPW33
IMS Product Code: 1897463
Packaging: Sold Individually
Description:
SKF NN3017KTN9/SPW33 Cylindrical Roller Bearing
Double-row precision cylindrical roller bearing with tapered bore (1:12), glass fibre reinforced polyamide cage, and lubrication groove with holes in outer ring. High radial load capacity and running accuracy.
Specifications
- Bore Type: Tapered 1:12
- Number Of Rows: 2
- Bore Diameter: 85 mm
- Outside Diameter: 130 mm
- Overall Width: 34 mm
- Internal Clearance: C1
- Max Rpm: 7000 rpm
- Bearing Material: Steel
- Cage Material: Polyamide
- Cage Type: Non-metallic
- Closure Type: Open
- Dynamic Load Rating: 125 kN
- Static Load Rating: 204 kN
- Fatigue Load Rating: 23.2 kN
- Reference Speed Rating: 7500 r/min
- Limiting Speed Rating: 6700 r/min
- Weight: 1.64 kg
- Precision: SP - Precision Higher than P4S
- Temperature Range: -30 to +120 degrees C
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 2 minutes.
