TB WOODS 6SC35 SPACER FLANGE
Quick Overview
Manufactured By: TB WOODS
Manufacturer Part Number: 6SC35
IMS Product Code: 2017889
Packaging: Sold Individually
Description:
TB Woods 6SC35 Spacer Flange
Spacer flange coupling component with 1.375 inch bore diameter and cast iron material.
Specifications
- Series: D-Flex
- Coupling Size: 6
- Bore Diameter: 1.375 in
- Hub Type: Spacer Flange
- Material: Cast Iron
- Flange Diameter: 4 in
- Length Through Bore: 1.625 in
- Distance Between Shafts: 3.5 in
- Torque Capacity: 1800 in-lb
- Max RPM: 6000 rpm
- Max Angular Misalignment: 1 degrees with EPDM/neoprene sleeves and 0.25 degrees with hytrel sleeves
